Free Porsche Parts Catalogs & Codes

Find genuine parts for your classic car, we offer an easy access to the official catalogs for Porsche Classic Genuine Parts. Free Download Porsche PET below.

Quick Links: 356 / 911 / 914 / 924 / 928 / 944 / 968 / Boxster / Cayman / Cayenne / Panamera / Macan / Supercars / Misc

Porsche Part Diagrams, Codes & Catalogs

First Porsches were built from thousands of parts, new ones from tens of thousands (if you count down to the smallest washer). Some parts are interchangeable between different models, but most are unique. Each part has a unique spare part number. While the 356 had 8-digit part numbers, a 11-digit spare part number system was implemented with the 901 (911). It is most tricky to get the right interior parts as they are available in different materials and in different shades of colors. Every such part has a supplemental 3-digit material/color code which is different from the material/color code when the car was ordered new (the code on the sticker). It is rather confusing that Porsche sales and service systems use different color codes. The parts with color code have 14-character codes. It is easiest to order the parts at the Porsche dealer using the VIN code of your car.

The Easy Parts Finder For Your Porsche

If you prefer to check the spare part codes on your own, Porsche has made the part catalogs - known as PET (Porsche ErsatzTeile = Porsche Spare Parts) available for download to everyone and we’ve created a list of them so you can directly download the one you need.

A Guide To The Meaning Behind Porsche’s Part Numbers. What You Need to Know to Understand Porsche Parts.

Consider yourself a Porsche DIY person? Want to save a few dollars by buying parts directly? In either case, you need to learn about PET and how Porsche part numbers work. You may have already stumbled across those 11 digit numbers (000-000-000-00). Today, we are going to explain it all to you, so you can understand how part companies and dealerships know how to translate the code to get you the parts you need. Note, these are generalized rules and as always Porsche isn't always 100% consistent.

Let's start by dividing the 11 digit numbers into four smaller chunks:

The first three digits xxx-000-000-00

Most Porsche parts use a 3 digit prefix that connects them to a specific model in the Porsche range (almost always the one that they were first designed for).

Standard model prefixes include 901, 902, 911, 930, 914, 928, 964, 986 etc. which usually correlate to the model on which you will find them.
999, 900, or N denote hardware components with multiple uses.
There are lots of VW part numbers. For example 022 and 021 are common
The 924/944/968 were going to be Volkswagens using existing components , so expect many of these components use VW part numbers.
The automatic transmission found in the 928 is a model that was developed with Mercedes Benz. Uses their part numbering system
Transmission or Engine parts can often receive their own prefix based on the number of that engineering exercise – 915, 741, 547, 950, etc.

The second three digits 000-xxx-000-00

The first number in this second series of three digits signifies the section/system of the Porsche where the part can be found (i.e. Engine, Transmission, Front Suspension, Rear Suspension, etc.). The final two numbers in the series are related to the diagram number, within Porsche's PET system, on which they can be found. Using the below outline, I'll explain which numbers correlate to which system, and list a few of the components that can be found there.

100 – Engine
200 – Fuel and Exhaust
300 – Transmission
400 – Front Axle/Steering
500 – Rear Axle
600 – Wheels/Brakes
700 – Levers/Pedals
800 – Body
900 – Electrical

The third three digits 000-000-xxx-00

These are an internal code for the “actual number of the part”. This does not seem to have any significance or method to it.

The final two digits 000-000-000-xx

These are known as the “modification number”. For the most part, Porsche produced parts end in a pair of zeros. When you see something other than these two zeros it means there has been a modification to the piece from its original production run. This could me a minor change in the material specification, or even a significant change in the exterior dimensions of the part. Either way, each subsequent modification will receive a new part number with an incrementally higher modification digit. Often, these modifications are completed before the part is even installed on a production-line automobile; however, occasionally there are super sessions that will replace an earlier number.

What is Porsche PET?

Porsche PET is the Porsche electronic parts catalog. It contains part numbers for For Porsche genuine parts. Electronic spare parts catalogue Porsche contains the full information on spare parts. The spare parts catalog Porsche allows a user to enter VIN number of the machine and carries out a filtration, using it, but thus number of a body is not taken into account, that is the program Porsche will define on VIN model and modeling year (using first 11 symbols VIN), the rest should be chosen independently.

It means, that the program Porsche easy digests VIN numbers with thought up last figures that can lead to to mistakes in identification of units. In the program there is a function of search of application spare parts, she allows to search application of a detail, and also the information concerning to replacements and returnable parts, the information about “fractional” the deputy. At work with the given catalogue, it is necessary to pay special attention to various footnotes and notes, and also if necessary to look in lists of fractional replacements and V, S and P-page more often to not receive a detail which you did not wait.

Porsche 356 Parts Catalog

Porsche 356 parts codes, catalogs and diagrams
